The Synthes Maintenance Unit (REF 05.001.099) is a dedicated device used to service, lubricate and maintain surgical handpieces and attachments in the Electric Pen Drive (EPD) and Air Pen Drive (APD) systems. It combines electrical drive and compressed air to deliver precise lubrication of the internal components of handpieces and attachments, aiding in smooth operation and long-term reliability. The unit is designed for use by maintenance departments or authorized service centers and helps ensure that the EPD/APD instruments continue to perform optimally in surgical settings.
Technical Specifications:
| Parameter: | Specification: |
|---|---|
| Manufacturer / Brand | DePuy Synthes / Synthes (Johnson & Johnson Medical Devices) |
| Model / REF | 05.001.099 Maintenance Unit (for EPD and APD) |
| Intended Use | Lubrication and maintenance of Electric Pen Drive and Air Pen Drive handpieces / attachments |
| Power Supply / Electrical | Input: 100-240 V AC, 50/60 Hz (country-specific) Internal output: 24 V DC to the unit’s internal systems |
| Pneumatic Input | Compressed air supply: 5–10 bar (70–145 psi) required for lubrication process |
| Weight | Approx. 4.7 kg |
| Dimensions | ~ 330 × 200 × 165 mm |
| Protection / Rating | IP X0 (no special ingress protection) |
| Degree of Insulation / Safety | Double insulated (Class II) per medical equipment standards |
| Oil Reservoir | Internal reservoir for Synthes Special Oil (05.001.095) required for lubrication cycles |
| Accessories / Scope | Includes power supply, pneumatic connection, filter, oil and country-specific power cord |
| Restrictions / Notes | – Unit must not be sterilised. – Only Synthes original oil / spray and parts recommended; use of others may void warranty or degrade performance. – Do not expose to moisture or explosive atmospheres. |
1X Used unit, in excellent condition in stock.
Immediately available for dispatch, patient ready and this product is offered with a 12 month warranty period.
