NDS Radiance 24″ HD LCD Surgical Monitor

The NDS Radiance SC-WU24-A1511 is a state-of-the-art 24-inch HD surgical display monitor designed for use in high-performance operating room environments. Engineered with NDSsi® Radiance® technology, this monitor delivers superior image clarity, true-to-life color reproduction, and ultra-low latency—ideal for endoscopy, minimally invasive surgery, and other advanced visualization procedures. With a robust medical-grade build, full HD resolution, and a wide array of connectivity options, the SC-WU24-A1511 sets the standard for surgical imaging excellence.

Technical Specifications

Key Features

• Full HD 1080p Resolution: Offers sharp, precise visuals for surgical imaging and medical video sources.

• Radiance® High-Brightness Display: Optimized for use in bright OR environments, ensuring visibility without color washout or glare.

• Advanced Connectivity: Supports both digital and analog signal types including HDMI, SDI, DisplayPort, and Component.

• Medical-Grade Construction: Rugged and sealed for use in sterile fields; features anti-reflective, easy-to-clean protective glass.

• Ultra-Low Latency Performance: Ideal for real-time procedures such as laparoscopic surgery and image-guided interventions.

• Wide Viewing Angle: Enables clinical teams to view critical information from multiple positions without image distortion.

• Loop-Through Capability: Allows video signals to be shared simultaneously with secondary displays or recording systems.

• Flexible Mounting Options: Compatible with wall, boom arm, or cart mounting configurations for surgical suite integration.

• Trusted NDSsi Quality: Built by NDS Surgical Imaging, a global leader in medical-grade visualization technology.

  The NDS Radiance SC-WU24-A1511 is a state-of-the-art 24-inch HD surgical display monitor designed for use in high-performance operating room environments. Engineered with NDSsi® Radiance® technology, this monitor delivers superior image clarity, true-to-life color reproduction, and ultra-low latency—ideal for endoscopy, minimally invasive surgery, and other advanced visualization procedures. With a robust medical-grade build, full HD resolution, and a wide array of connectivity options, the SC-WU24-A1511 sets the standard for surgical imaging excellence.

  ---

  Technical Specifications

  Specification	Details
  Model	SC-WU24-A1511
  Display Size	24 inches
  Resolution	Full HD 1920 × 1080
  Aspect Ratio	16:9
  Panel Type	LCD with LED backlight and Radiance® technology
  Color Support	16.7 million colors
  Brightness	600 cd/m²
  Contrast Ratio	1000:1
  Viewing Angle	178° horizontal / vertical
  Response Time	< 10 ms
  Video Inputs	DVI-D, HDMI, 3G-SDI, DisplayPort, Component, Composite
  Output Ports	SDI loop-through, DVI loop-through
  Enclosure	Sealed, anti-reflective, disinfectant-safe medical-grade glass
  Certifications	IEC 60601-1, CE, RoHS, UL Medical Certified
  Mounting Compatibility	VESA 100 × 100 mm / 200 × 100 mm
  Power Supply	100–240V AC, 50/60Hz
  Power Consumption	Approx. 60W
  Dimensions (W × H × D)	Approx. 590 × 400 × 85 mm
  Weight	Approx. 7.8 kg

  ---

  Key Features

  • Full HD 1080p Resolution: Offers sharp, precise visuals for surgical imaging and medical video sources.

  • Radiance® High-Brightness Display: Optimized for use in bright OR environments, ensuring visibility without color washout or glare.

  • Advanced Connectivity: Supports both digital and analog signal types including HDMI, SDI, DisplayPort, and Component.

  • Medical-Grade Construction: Rugged and sealed for use in sterile fields; features anti-reflective, easy-to-clean protective glass.

  • Ultra-Low Latency Performance: Ideal for real-time procedures such as laparoscopic surgery and image-guided interventions.

  • Wide Viewing Angle: Enables clinical teams to view critical information from multiple positions without image distortion.

  • Loop-Through Capability: Allows video signals to be shared simultaneously with secondary displays or recording systems.

  • Flexible Mounting Options: Compatible with wall, boom arm, or cart mounting configurations for surgical suite integration.

  • Trusted NDSsi Quality: Built by NDS Surgical Imaging, a global leader in medical-grade visualization technology.
